JHEMCU GF30F722-ICM – F7 Flight Controller with OSD, Barometer and Dual BEC

High-performance flight controller for FPV – STM32F722, 5V/10V BEC, 3–8S LiPo

JHEMCU GF30F722-ICM is an advanced flight controller designed for FPV racing and freestyle drones. Powered by a STM32F722RET6 processor, it includes a ICM-42688-P gyro, DPS310 barometer, and AT7456E OSD for precise control and full telemetry. With support for 3–8S LiPo batteries and dual BEC outputs (5V/2.5A and 10V/2A), it delivers excellent power flexibility for your FPV gear such as cameras, VTXs, or GPS modules.

Product Features:

  • ✅ STM32F722RET6 processor – fast and reliable operation
  • ✅ ICM-42688-P gyro + DPS310 barometer – accurate flight data
  • ✅ Dual BEC output: 5V/2.5A and 10V/2A – power flexibility
  • ✅ Integrated OSD (AT7456E) + 16MB blackbox
  • ✅ 3–8S LiPo input supported – wide voltage range
  • ✅ 6 full UART ports – excellent expandability
  • ✅ Standard 30.5×30.5 mm mounting – perfect for stacks

📋 Technical Specifications:

  • Processor: STM32F722RET6
  • Gyroscope: ICM-42688-P
  • Barometer: DPS310
  • OSD: AT7456E
  • Blackbox: 16MB flash memory
  • Input voltage: 3–8S LiPo (11.4–36V)
  • BEC outputs: 5V/2.5A ±0.1V and 10V/2A
  • Supported receivers: ELRS (CRSF), TBS (CRSF), SBUS, IBUS, DSM2, DSMX
  • UART ports: UART1–UART6
  • I2C port: I2C1
  • ESC signal support: PWM, Oneshot125/42, Multishot, DShot150/300/600
  • LED strip support: Yes
  • Buzzer output: 5V
  • USB: Type-C
  • Current and voltage sensor: Integrated
  • DFU button: Yes
  • Firmware: Betaflight 4.3.1 (JHEF7DUAL.HEX)
  • Board size: 36×36 mm
  • Mounting holes: 30.5×30.5 mm (M4, with grommets)
  • Weight: approx. 8.8 g

📦 Package Includes:

  • 1× JHEMCU GF30F722-ICM Flight Controller
