FNIRSI® DST-210 – 3-in-1 Oscilloscope, Multimeter & Signal Generator

217.77
Tax included
Avifly - official distributor of FNIRSI

Brand
Fnirsi
Quantity:
15
Shipment:

Today!

Supply:
for freeCheck delivery costs
Gift:
Soon!

FNIRSI® DST-210 – 3-in-1 Oscilloscope, Multimeter & Signal Generator

Handheld multifunction tester with 2.8" TFT screen, 10 MHz bandwidth and 48 MSa/s sampling rate

The FNIRSI DST-210 combines the functions of a digital oscilloscope, True RMS multimeter, and waveform generator in a single compact device. Featuring 10 MHz bandwidth, 48 MSa/s sampling, and a bright 2.8" color TFT screen, it’s ideal for quick diagnostics, education, and fieldwork. Built-in rechargeable 3000 mAh battery provides up to 15 hours of use.

Key Features

  • ● 10 MHz oscilloscope with 48 MSa/s sampling rate
  • ● 4.5-digit True RMS multimeter (voltage, current, resistance, etc.)
  • ● Built-in signal generator with 13 waveforms, up to 50 kHz
  • ● 2.8" TFT display with brightness control and dark/light mode
  • ● 3000 mAh battery – up to 15 hours of operation
  • ● Portable and compact: 177×87×35 mm; weight: 300 g

Technical Specifications

  • ● Power input: 5 V / 1 A (USB-C charging)
  • ● Voltage range: DC up to 1000 V, AC up to 750 V
  • ● Current range: DC/AC up to 10 A
  • ● Resistance: up to 20 MΩ; Capacitance: up to 100 mF
  • ● Temperature: -55 °C to 1300 °C (with probe)
  • ● Signal generator: 13 waveform types, 0–50 kHz, 0.1–3 V output

Package Contents

  • ● 1× FNIRSI DST-210 device
  • ● 1× USB-C charging cable
  • ● 1× Pair of multimeter test leads
  • ● 1× User manual
  • Note: Oscilloscope probe, power adapter, and carrying case are not included.
Compact test tool for electronics – DST-210
Compact test tool for electronics – DST-210

FAQ

Frequently Asked Questions about FNIRSI DST-210 (Oscilloscope + Multimeter + Signal Generator)

It’s a 3-in-1 device: digital oscilloscope (10 MHz, 48 MSa/s), True RMS multimeter (up to 1000 V DC / 750 V AC), and signal generator with 13 waveforms (0–50 kHz) .

Yes – it offers Auto, Normal, and Single modes with rising or falling edge triggering .

It supports 13 waveform types, including sine, square, triangle, and sawtooth, with adjustable amplitude (0.1–3 V) and duty cycle (0–100%) .

The multimeter measures AC/DC voltage, current, resistance, capacitance, frequency, temperature (–55…1300 °C), diode testing, and continuity .

​

It features a 2.8" TFT color screen, 3000 mAh battery (up to 15 h operation), USB-C charging (5 V/1 A), dimensions of 177 × 87 × 34 mm, and weighs approximately 300 g .
