Amass Silicone Wire 12 AWG 1 m – Flexible Cable for FPV Drones, RC and Electronics (8 Colors)

8.46
Tax included
  • ● Amass Silicone Wire 12 AWG – 1 m
  • ● Tinned copper multi-strand • high flexibility • low resistance
  • ● 4 colors: red, black, blue and white
  • ● Sold per meter – longer lengths shipped in one piece
  • ● Perfect for LiPo batteries, ESC, converters and 12–48 V DC systems

Color
Brand
Amass
Quantity:
692
Shipment:

Up to 24 hours

Supply:
for freeCheck delivery costs
Gift:
Soon!

You might also like

Amass Silicone Wire 12 AWG – Flexible Power Cable for LiPo, RC and FPV

Available in 8 colors: red, black, blue, white, green, yellow, purple and brown

The Amass 12 AWG wire is a premium tinned copper cable with soft silicone insulation for medium and high-current applications. It combines low resistance, excellent flexibility and heat resistance from –60 °C to 200 °C. Perfect for LiPo battery leads, ESC units, motors and 12–48 V DC power systems.

Technical Specifications

  • AWG: 12
  • Cross-sectional area: ≈ 3.31 mm²
  • Conductor diameter (without insulation): ≈ 2.0 mm
  • Outer diameter (with insulation): ≈ 3.8 mm
  • Conductor material: Tinned copper (multi-strand)
  • Insulation: Soft silicone – heat and abrasion resistant
  • Rated voltage: 600 V
  • Operating temperature: –60 °C to 200 °C
  • Colors: red, black, blue, white, green, yellow, purple, brown

Product Features

  • Multi-strand tinned copper wire – excellent conductivity and corrosion resistance
  • Soft silicone insulation – highly resistant to heat, wear, and mechanical stress
  • High flexibility – wire does not retain bends and easily fits in tight spaces
  • Stable performance across a wide temperature range from –60°C to 200°C
  • Easy to solder – tinned copper strands and flexible silicone insulation

How to Choose the Right 12 AWG Wire

The Amass 12 AWG wire is ideal for medium-current applications where efficiency and flexibility matter. With a 3.31 mm² core, it supports continuous currents up to 35 A and peaks to 80 A. Its soft silicone insulation makes installation easy and resists heat and mechanical stress.

Typical 12 AWG Applications:

  • LiPo battery and ESC connections in RC models
  • Brushless motor and controller power leads
  • 12–48 V DC installations in audio and workshop systems
  • Ground and chassis connections

Why Silicone?

  • Maintains flexibility across a wide temperature range
  • Does not crack, melt, or deform even under long-term heat exposure
  • No “memory effect” – ideal for compact or mobile installations

Applications

  • FPV drone and RC model wiring (ESC, power lines, LED strips)
  • DIY electronics projects and prototyping
  • Power supply connections for modules, sensors, and controllers
  • Applications requiring flexibility and high temperature resistance

Practical Parameters (12 AWG)

  • Continuous current: ≈ 35 A
  • Peak current: up to 80 A
  • Resistance: ≈ 5.2 mΩ/m
  • Voltage range: 6 – 60 V DC

Assembly Tips

  • Choose the proper AWG size based on current load and wire length
  • Use flux and a clean soldering tip for solid, low-resistance joints
  • Protect solder joints with heat-shrink tubing

Package Contents

  • 1 piece = 1 meter of Amass silicone wire – chosen color and AWG size

The Amass 12 AWG silicone wire combines high flexibility, low resistance and durability. Perfect for FPV, RC, robotics, power supplies and custom electronic builds. Available in 8 colors: red, black, blue, white, green, yellow, purple and brown.

FAQ

Frequently Asked Questions – Amass 12 AWG

The Amass 12 AWG wire is designed for high-current power applications.
It’s perfect for LiPo batteries, ESCs, high-power motors and 12 – 48 V FPV power systems.

I am item content. Click edit The 12 AWG wire safely carries about 35 A continuous and up to 80 A peak.

Over short runs, it can handle up to 100 A with minimal voltage drop. to change this text. Lorem ipsum dolor sit amet, adipiscing elit. Ut elit tellus, luctus nec mattis, pulvinar dapibus leo.

Yes, 12 AWG is commonly used in large FPV drones (7 – 10 inch) and high-power RC systems.
It’s ideal for battery leads, PDB connections and heavy duty DC power wiring.

Use a 4 – 5 mm soldering tip at 420 – 450 °C.
Heat the wire for 2–3 seconds to let solder fully flow into the strands.
The Amass silicone insulation is heat-resistant and won’t melt while soldering.

The 12 AWG wire has a cross-section of ≈ 3.31 mm², while 14 AWG is ≈ 2.08 mm².
12 AWG handles more current but is thicker and heavier; 14 AWG is more flexible for smaller builds.
