HDZero BoxPro / BoxPro+ FPV Box Goggles 100Hz LCD for Digital, Analog and HDMI
0.00
Tax included
HDZero BoxPro / BoxPro+ FPV Box Goggles for Digital, Analog and HDMI
Versatile FPV box goggles with 100Hz LCD, ultra low latency and support for HDZero, analog and HDMI
HDZero BoxPro / BoxPro+ are high-performance FPV box goggles built for pilots who need flexibility, clarity and low latency without paying flagship prices. The 100Hz, 1800 nits LCD with a 56° field of view delivers a bright and immersive image, while support for HDZero digital, analog and HDMI video makes these goggles a true all-in-one solution.
Key Features
- • 100Hz LCD display, about 1800 nits brightness and 56° FOV for crisp daylight visibility
- • Supports HDZero digital, analog FPV and HDMI input/output in a single goggle
- • Very low latency: about 1 ms on HDMI, 3 ms on analog and 4 ms on HDZero
- • Four antenna system: two inbuilt high-gain patch antennas and two external linear SMA antennas
- • Integrated H.265 DVR for HDZero, analog and HDMI with multiple recording modes
- • Glasses-friendly design with optional diopter inserts, adjustable foam and head strap with battery pocket
- • Power via XT60 from 2S–6S LiPo batteries (battery not included)
Differences between BoxPro and BoxPro+
| Feature | HDZero BoxPro | HDZero BoxPro+ |
| WiFi video streaming | No | Yes, streaming to iOS/Android/PC via VLC or FPV Mate |
| ELRS backpack (ESP32) | No | Yes, syncs channel, DVR start/stop and head tracking with ELRS radios |
| ELRS workflow | Standard usage without backpack integration | Integrated workflow for ELRS pilots and shared profiles |
| Other functions | Full HDZero, analog and HDMI support with H.265 DVR | Same features as BoxPro plus WiFi and ELRS backpack |
Technical Specifications
| Category | Specification |
| Display | 100Hz LCD, about 1800 nits, 56° field of view |
| Digital input | Mini HDMI input and output, up to 100Hz |
| Analog input | Integrated analog receiver, 3.5mm AV input |
| DVR | Built-in H.265 DVR, records HDZero, analog and HDMI (720p60/90/100, 1080p60, H.264/H.265) |
| Audio | Built-in microphone, line-in and AV-in audio sources |
| Latency | About 1 ms HDMI, 3 ms analog, 4 ms HDZero camera |
| Antenna system | 2 internal high-gain patch antennas + 2 external linear SMA 5.8GHz antennas |
| Power input | XT60, 2S–6S LiPo battery (battery not included) |
| Cooling | Adjustable internal fan for cooling and anti-fog |
| Software platform | Linux-based open-source firmware with customizable UI |
What's Included
- • 1 × HDZero BoxPro or BoxPro+ goggles (depending on selected variant)
- • 2 × Linear 5.8GHz SMA antennas
- • 2 × Internal high-gain patch antennas (integrated)
- • 1 × Foam face pad
- • 1 × Adjustable head strap with battery pocket
- • 1 × 1200 mm XT60 power cable
- • 1 × Durable canvas goggle bag
- • 1 × Lens cleaning cloth
Use Cases
- • HDZero digital quads, analog FPV drones, ground stations and HDMI simulators
- • Racing, freestyle and long practice sessions in bright outdoor conditions
- • Perfect choice for ExpressLRS pilots, especially with the BoxPro+ variant
.webp)
.webp)
.webp)
.webp)
.webp)
.webp)
.webp)
